RJR24FW102R | Bourns Electronics GmbH
Cermet trimmer potentiometer, 25 turns, 1 kΩ, 0.5 W, THT, on top, RJR24FW102R
Order No.: 76E2787
EAN: 4099879894397
MPN:
RJR24FW102R
Unit Price (€ / pc.)
8.8060 € *
Standard delivery time from the manufacturer is: 14 Weeks
Trimming potentiometer, RJR24FW102R, Bourns Electronics GmbH
Trimming potentiometer commonly used for fine-tuning electrical circuits. Designed with a standoff feature, which allows it to be mounted securely on a circuit board or other electronic devices.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 1 kΩ | |
| max. operating temperature | 100 °C | |
| Seeting | on top | |
| Length | 9.53 mm | |
| min. operating temperature | -40 °C | |
| Height | 10.03 mm | |
| Assembly | THT | |
| Width | 4.83 mm | |
| Track Taper | linear | |
| Power | 0.5 W | |
| Connection | solder pin | |
| Temperature coefficient | ±100 ppm/K | |
| Version | cermet trimmer potentiometer | |
| Tolerance | ±10 % | |
| max. number of revolutions | 25 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85334010 |
| MSL | MSL 2 |
| Original Packaging | Bar with 200 pieces |
| Country of origin | CR |
Compliance
| Property | Value |
|---|---|
| Substance description | Cadmium, lead |
| RoHS conform | No |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
