3352W-1-502LF | Bourns Electronics GmbH
Cermet trimmer potentiometer, 5 kΩ, 0.5 W, THT, lateral, 3352W-1-502LF
Order No.: 78E4562
EAN: 4099879927460
MPN:
3352W-1-502LF
Unit Price (€ / pc.)
2.2848 € *
Standard delivery time from the manufacturer is: 11 Weeks
Trimmer potentiometer, 3352W-1-502LF, Bourns
Trimmer potentiometer, 5 kΩ, 0.5 W
Features
- Single-Turn / Cermet / Industrial / Open Frame
- Stable cermet element offers infinite resolution
- Very low profile
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 5 kΩ | |
| max. operating temperature | 125 °C | |
| Seeting | lateral | |
| Length | 9.53 mm | |
| min. operating temperature | -55 °C | |
| Height | 5.08 mm | |
| Assembly | THT | |
| Contact distance | RM 2.54 | |
| Width | 7.62 mm | |
| Rotary range, electrical | 205 ° | |
| Power | 0.5 W | |
| Connection | solder pin | |
| Temperature coefficient | ±100 ppm/K | |
| Mechanic rotary range | 250 ° | |
| Version | cermet trimmer potentiometer | |
| Tolerance | ±20 % | |
| max. number of revolutions | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85334010 |
| MSL | MSL 2 |
| Original Packaging | Bar with 100 pieces |
| Country of origin | MX |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
