3260W-1-102 | Bourns Electronics GmbH
Trimmer potentiometer, 11 turns, 1 kΩ, 0.25 W, THT, on top, 3260W-1-102
Order No.: 78E2236
EAN: 4099879907424
MPN:
3260W-1-102
Unit Price (€ / pc.)
34.2363 € *
Standard delivery time from the manufacturer is: 10 Weeks
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height | 6.35 mm | |
| Length | 6.35 mm | |
| Power | 0.25 W | |
| Contact distance | RM 2.54 | |
| Temperature coefficient | ±70 ppm/K | |
| max. operating temperature | 150 °C | |
| Connection | solder pin | |
| min. operating temperature | -65 °C | |
| Track Taper | linear | |
| Version | trimmer potentiometer | |
| Assembly | THT | |
| max. number of revolutions | 11 | |
| Width | 4.32 mm | |
| Seeting | on top | |
| Tolerance | ±5 % | |
| Rotary range, electrical | 3960 ° | |
| ohmic resistance | 1 kΩ |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Original Packaging | Bulk with 25 pieces |
| Customs tariff number | 85334010 |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
