3224W-1-201E | Bourns Electronics GmbH
Cermet trimmer potentiometer, 12 turns, 200 Ω, 0.25 W, SMD, on top, 3224W-1-201E
Unit Price (€ / pc.)
4.4268 € *
Available: 0 pcs.
Next delivery: 185 pcs. on 2025-05-19
Leadtime: 11 Weeks **
Total Price:
4.43 € *
Price list
Quantity
Price per unit*
1 pcs.
4.4268 €
10 pcs.
3.1535 €
100 pcs.
2.7013 €
500 pcs.
2.3443 €
1000 pcs.
2.1420 €
*incl. VAT plus shipping costs
**Subject to prior sale
SMD Cermet trimmer potentiometer, 3224W-1-201E, Bourns
SMD Cermet trimmer potentiometer, 200 Ω, 0.25 W
Features
- Surface Mount 4 mm Square / Multiturn Cermet / Industrial / Sealed
- Sealed to withstand board wash processing
- Pick and place centering design, with flush adjustment
Technical specifications
| ohmic resistance | 200 Ω | |
| Connection | J-hook | |
| Version | Cermet-Trimmpotentiometer | |
| Width | 3.5 mm | |
| Rotary range, electrical | 4320 ° | |
| Seeting | oben | |
| Height | 5.3 mm | |
| Contact distance | RM 2,5 | |
| Length | 4.8 mm | |
| Power | 0.25 W | |
| max. number of revolutions | 12 | |
| max. operating temperature | 150 °C | |
| min. operating temperature | -65 °C | |
| Assembly | SMD | |
| Tolerance | ±10 % | |
| Temperature coefficient | ±100 ppm/K | |
| Track Taper | linear |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85334010 |
| MSL | MSL 1 |
| Original Packaging | Rolle mit 250 Stück |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Blei |
