PWR3014W1R00JE | Bourns Electronics GmbH

Name: Resistor, wirewound, SMD 3014, 1 Ω, 1 W, ±5 %, PWR3014W1R00JE
Brand: Bourns Electronics GmbH
SKU: 07E7545
Availability: OutOfStock

Resistor, wirewound, SMD 3014, 1 Ω, 1 W, ±5 %, PWR3014W1R00JE

Order No.: 07E7545

EAN: 4099879196163

MPN:

PWR3014W1R00JE

Image may differ

Key Specification:

ohmic resistance 1 Ω

Tolerance ±5 %

Power 1 W

Design SMD 3014

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.7259 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,088.85 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

SMD Wirewound resistor, PWR3014W1R00JE, Bourns

Resistor, Wirewound, SMD 3014, 1 Ω, 1 W, ±5 %

Features

Large terminals and optimized body shape for power dissipation
Excellent surge capabilities
Low TCR
RoHS compliant

Technical specifications

Filter	Property	Value
	Temperature coefficient	±50 ppm/K
	Technology	wirewound
	Height	4.64 mm
	Power	1 W
	Length	7.5 mm
	Design	SMD 3014
	min. operating temperature	-55 °C
	Tolerance	±5 %
	max. operating temperature	155 °C
	ohmic resistance	1 Ω
