PWR2010W1001FE | Bourns Electronics GmbH

Name: Resistor, wirewound, SMD 2010 (5025), 1 kΩ, 0.5 W, ±1 %, PWR2010W1001FE
Brand: Bourns Electronics GmbH
SKU: 07E6878
Availability: OutOfStock

Resistor, wirewound, SMD 2010 (5025), 1 kΩ, 0.5 W, ±1 %, PWR2010W1001FE

Order No.: 07E6878

EAN: 4099879192073

MPN:

PWR2010W1001FE

Image may differ

Key Specification:

ohmic resistance 1 kΩ

Tolerance ±1 %

Power 0.5 W

Design SMD 2010 (5025)

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.9877 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

2,469.25 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

SMD Wirewound resistor, PWR2010W1001FE, Bourns

Resistor, Wirewound, SMD 2010, 1 kΩ, 0.5 W, ±1 %

Features

Large terminals and optimized body shape for power dissipation
Excellent surge capabilities
Low TCR
RoHS compliant

Technical specifications

Filter	Property	Value
	Temperature coefficient	±20 ppm/K
	Technology	wirewound
	Width	2.5 mm
	Height	3.25 mm
	Power	0.5 W
	Length	5.08 mm
	Design	SMD 2010 (5025)
	min. operating temperature	-55 °C
	Tolerance	±1 %
	max. operating temperature	155 °C
	ohmic resistance	1 kΩ
