CRK0612-FZ-R005E | Bourns Electronics GmbH
Resistor, metal strip, SMD 0612, 5 mΩ, 1 W, ±1 %, CRK0612-FZ-R005E
Order No.: 11E955
EAN: 4099879207784
MPN:
CRK0612-FZ-R005E
Unit Price (€ / pc.)
0.2535 € *
Standard delivery time from the manufacturer is: 18 Weeks
Metal strip, CRK0612-FZ-R005E, BOURNS
Metal strip, Wide terminal current sense resistor.
Features
- Wide terminal type
- Excellent heat dissipation
- High reliability
- Metal alloy plate
- RoHS compliant
Applications
- Current sensing
- Power supplies
- Stepper motor drives
- Input amplifiers
Technical specifications
| Temperature coefficient | ±50 ppm/K | |
| Technology | metal strip | |
| Width | 1.65 mm | |
| Height | 0.6 mm | |
| Power | 1 W | |
| Length | 3.2 mm | |
| Design | SMD 0612 | |
| min. operating temperature | -55 °C | |
| Tolerance | ±1 % | |
| max. operating temperature | 170 °C | |
| ohmic resistance | 5 mΩ |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85332100 |
| MSL | MSL 1 |
| Original Packaging | Reel with 5,000 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
