CR2512-FX-8200ELF | Bourns Electronics GmbH
Resistor, thick film, SMD 2512 (6330), 820 Ω, 1 W, ±1 %, CR2512-FX-8200ELF
Unit Price (€ / pc.)
0.1226 € *
Available: 0 pcs.
Leadtime: 11 Weeks **
Resistor, CR2512-FX-8200ELF, BOURNS
The CR2512-FX-8200ELF is a thick film resistor with three layer termination process with nickel barrier helps prevent leaching and provides excellent solderability.
Features
- RoHS compliant
- Tight tolerance of bottom electrode width
Technical specifications
| ohmic resistance | 820 Ω | |
| Design | SMD 2512 (6330) | |
| Width | 3 mm | |
| Height | 0.6 mm | |
| Length | 6.3 mm | |
| Power | 1 W | |
| max. operating temperature | 155 °C | |
| min. operating temperature | -55 °C | |
| Tolerance | ±1 % | |
| Technology | thick film | |
| Temperature coefficient | ±100 ppm/K |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85332100 |
| MSL | MSL 1 |
| Original Packaging | Reel with 4,000 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
