4606X-101-222LF | Bourns Electronics GmbH
Resistor network, SIP-6, 2.2 kΩ, 0.2 W, ±2 %, 5 resistors, 4606X-101-222LF
Unit Price (€ / pc.)
0.4522 € *
Standard delivery time from the manufacturer is: 19 Weeks
Total Price:
0.45 € *
Price list
Quantity
Price per unit*
1 pcs.
0.4522 €
10 pcs.
0.3927 €
100 pcs.
0.2832 €
1000 pcs.
0.1904 €
3000 pcs.
0.1416 €
*incl. VAT plus shipping costs
Subject to prior sale
Resistance networks, type Bourns 4600X.
Thickfilm, SiL (Single-in-Line) resistors (same value), interconnected, common connection (bussed resistors)
With 5 resistors, 6-pole, type 4606X-101-RC.
Technical specifications
| Height | 5.08 mm | |
| Power | 0.2 W | |
| Tolerance | ±2 % | |
| Length | 15.19 mm | |
| Width | 2.49 mm | |
| Temperature coefficient | ±100 ppm/°C | |
| max. operating temperature | 125 °C | |
| Number of resistors | 5 | |
| Enclosure | SIP-6 | |
| ohmic resistance | 2.2 kΩ | |
| Assembly | THT |
Download
Logistics
| Original Packaging | Bulk with 200 pieces |
| MSL | MSL 1 |
| Customs tariff number | 85332100 |
| Country of origin | JP |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
