4116R-1-474LF | Bourns Electronics GmbH
Resistor network, DIP-16, 470 kΩ, 0.25 W, ±2 %, 8 resistors, 4116R-1-474LF
Unit Price (€ / pc.)
1.2614 € *
Standard delivery time from the manufacturer is: 11 Weeks
Resistance networks, type Bourns 4100R.
Thickfilm, DiL (Dual-in-Line) resistors, not interconnected, separately insulated, all resistors of the same value and with separate connection (isolated resistors)
With 8 resistors, 16-pole, type 4116R-001-RC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | THT | |
| Power | 0.25 W | |
| max. operating temperature | 125 °C | |
| Temperature coefficient | ±100 ppm/°C | |
| Width | 8.64 mm | |
| ohmic resistance | 470 kΩ | |
| Height | 4.57 mm | |
| Enclosure | DIP-16 | |
| Number of resistors | 8 | |
| Tolerance | ±2 % | |
| Length | 21.97 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CR |
| Original Packaging | Bar with 25 pieces |
| Customs tariff number | 85332100 |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
