51SAD-U25-B15L | Bourns Electronics GmbH
Conductive plastic potentiometer, 10 kΩ, 0.5 W, linear, solder pin, 51SAD-U25-B15L
Unit Price (€ / pc.)
10.0436 € *
Available: 92 pcs.
Total Price:
10.04 € *
Price list
Quantity
Price per unit*
1 pcs.
10.0436 €
10 pcs.
8.8417 €
45 pcs.
8.2824 €
180 pcs.
7.8064 €
360 pcs.
7.5208 €
*incl. VAT plus shipping costs
Subject to prior sale
Potentiometer, 51SAD-U25-B15L, Bourns Electronics GmbH
Sealed square control for board washing with metal bushing and shaft.
Features
- Gangable
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rotary range, electrical | 270 ° | |
| min. operating temperature | 1 °C | |
| Track Taper | linear | |
| max. operating temperature | 125 °C | |
| Version | conductive plastic potentiometer | |
| Connection | solder pin | |
| Assembly | angled | |
| max. number of revolutions | 1 | |
| Power | 0.5 W | |
| Mechanic rotary range | 290 ° | |
| ohmic resistance | 10 kΩ | |
| axle diameter | 3 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85334010 |
| Country of origin | MX |
| Original Packaging | Tray with 45 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
