AMS22B5A1BLASL334S | Bourns Electronics GmbH
Analogue position sensor, -40 °C, 125 °C
Total price
(34.06 €
* / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
50 pcs.
34.06 €
*incl. VAT plus shipping costs
Please send price/quantity requests to info@buerklin.com
Description
Product by Bourns Electronics GmbH at Bürklin Elektronik
Non-contacting analog rotary position sensors, type Bourns AMS22B.
Supply voltage (VDD): 5.0 V. Linearity: ±0.5 %. Revolutions: max. 500/min. Operating temperatures: –40 to +125 °C. Degree of protection: IP 50.
Technical attributes (type, supply current, shaft version, w/o stop position): AMS22B5A1BLASL334S, 10 mA, slotted
Technical specifications
| Number of pins | 3 | |
| Version | analog | |
| max. operating temperature | 125 °C | |
| min. operating temperature | -40 °C | |
| Assembly | panel mounting | |
| Rated voltage (DC) | 5 V | |
| Rated current | 0.02 A | |
| Degree of protection (IP) | IP50 | |
| Revolutions | 3960 |
Logistics
| Country of origin | MX |
| Customs tariff number | 85414100 |
| Original Packaging | Tray with 25 pieces |
Compliance
| Exception code | 6C |
| Exception code description | Pb |
| Guidline date | 3/31/15 |
| RoHS confom | Yes |
| Substance CAS number | 7439-92-1 |
| Substance code | 1221 |
| Substance EC number | 231-100-4 |
| Substance description | Lead |
| SVHC date | 1/16/20 |
| SVHC free | No |
Download
Variations
Order No.:
18G562
Manufacturer:
Bourns Electronics GmbH
Manufacturer SKU
AMS22B5A1BLASL334S
50 pcs.
34.06 €
analog
panel mounting
-40 °C
5 V
3
125 °C
0.02 A
3960
IP50
Order No.:
18G560
Manufacturer:
Bourns Electronics GmbH
Manufacturer SKU
AMS22B5A1BHASL334N
50 pcs.
34.06 €
analog
panel mounting
-40 °C
5 V
3
125 °C
0.02 A
3960
IP50
Order No.:
18G561
Manufacturer:
Bourns Electronics GmbH
Manufacturer SKU
AMS22B5A1BLAFL334S
50 pcs.
34.06 €
analog
panel mounting
-40 °C
5 V
3
125 °C
0.02 A
3960
IP50
