SRU1048-470Y | Bourns Electronics GmbH
Power choke, SMD, 47 µH, SRU1048-470Y
Unit Price (€ / pc.)
1.3090 € *
Available: 100 pcs.
Total Price:
1.31 € *
Price list
Quantity
Price per unit*
1 pcs.
1.3090 €
10 pcs.
0.9401 €
100 pcs.
0.7854 €
500 pcs.
0.6783 €
1000 pcs.
0.6188 €
*incl. VAT plus shipping costs
Subject to prior sale
Power inductor, SRU1048-470Y, Bourns
Features
- Height of 4.8 mm
- Ferrite core
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
- Car radios
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Tolerance | ±30 % | |
| Saturation current | 1.5 A | |
| Design | SMD | |
| Width | 10 mm | |
| Quality Q | Q 26 | |
| Height | 4.8 mm | |
| Inductance | 47 µH | |
| Version | SMD choke | |
| Length | 10 mm | |
| DC resistance | 120 mΩ | |
| Measuring frequency | 2.52 MHz |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| Country of origin | CN |
| Original Packaging | Reel with 600 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
