SRU1048-150Y | Bourns Electronics GmbH
Power choke, SMD, 15 µH, SRU1048-150Y
Unit Price (€ / pc.)
1.2733 € *
Available: 580 pcs.
Leadtime: 18 Weeks **
Total Price:
1.27 € *
Price list
Quantity
Price per unit*
1 pcs.
1.2733 €
10 pcs.
0.9163 €
100 pcs.
0.7854 €
1200 pcs.
0.5593 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power inductor, SRU1048-150Y, Bourns
Features
- Height of 4.8 mm
- Ferrite core
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
- Car radios
Technical specifications
| Quality Q | Q 30 | |
| Saturation current | 2.7 A | |
| Width | 10 mm | |
| Height | 4.8 mm | |
| Length | 10 mm | |
| DC resistance | 40 mΩ | |
| Measuring frequency | 2.52 MHz | |
| Version | SMD choke | |
| Design | SMD | |
| Tolerance | ±30 % | |
| Inductance | 15 µH |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
