SRR6038-5R0Y | Bourns Electronics GmbH
Power choke, SMD, 5 µH, SRR6038-5R0Y
Order No.: 05D5748
EAN: 4099879999252
MPN:
SRR6038-5R0Y
Unit Price (€ / pc.)
0.6426 € *
Standard delivery time from the manufacturer is: 18 Weeks
Power inductor, SRR6038-5R0Y, Bourns
Features
- Height of 3 mm
- Ferrite core
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
Technical specifications
| Quality Q | Q 8.9 | |
| Saturation current | 2.95 A | |
| Width | 6.8 mm | |
| Height | 3.8 mm | |
| Length | 6.8 mm | |
| DC resistance | 24 mΩ | |
| Measuring frequency | 7.96 MHz | |
| Version | SMD choke | |
| Design | SMD | |
| Tolerance | ±30 % | |
| Inductance | 5 µH |
Download
Logistics
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
