SRR6038-3R3Y | Bourns Electronics GmbH
Power choke, SMD, 3.3 µH, SRR6038-3R3Y
Unit Price (€ / pc.)
0.4284 € *
Standard delivery time from the manufacturer is: 18 Weeks
Power inductor, SRR6038-3R3Y, Bourns
Features
- Height of 3 mm
- Ferrite core
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Quality Q | Q 9.8 | |
| Height | 3.8 mm | |
| Inductance | 3.3 µH | |
| Version | SMD choke | |
| Measuring frequency | 7.96 MHz | |
| DC resistance | 20 mΩ | |
| Saturation current | 3.6 A | |
| Tolerance | ±30 % | |
| Width | 6.8 mm | |
| Design | SMD | |
| Length | 6.8 mm |
Download
Logistics
| Property | Value |
|---|---|
| MSL | MSL 1 |
| Customs tariff number | 85045000 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
