SRR4018-100Y | Bourns Electronics GmbH
Power choke, SMD, 10 µH, SRR4018-100Y
Order No.: 05D5871
EAN: 4099889000405
MPN:
SRR4018-100Y
Unit Price (€ / pc.)
0.6188 € *
Standard delivery time from the manufacturer is: 18 Weeks
Power inductor, SRR4018-100Y, Bourns
Features
- Height of 2 mm
- High current rating
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
- Car radios
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 10 µH | |
| Length | 4.8 mm | |
| Saturation current | 1 A | |
| Design | SMD | |
| DC resistance | 150 mΩ | |
| Tolerance | ±30 % | |
| Width | 4.8 mm | |
| Measuring frequency | 2.52 MHz | |
| Quality Q | Q 10 | |
| Height | 1.8 mm | |
| Version | SMD choke |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
