SRR1280-680M | Bourns Electronics GmbH
Power choke, SMD, 68 µH, SRR1280-680M
Order No.: 05D5906
EAN: 4099889000627
MPN:
SRR1280-680M
Unit Price (€ / pc.)
1.0234 € *
Standard delivery time from the manufacturer is: 20 Weeks
Power inductor, SRR1280-680M, Bourns
Features
- Low inductance
- Ferrite core
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
- Car radios
Technical specifications
| Quality Q | Q 20 | |
| Saturation current | 2.3 A | |
| Width | 12.5 mm | |
| Height | 7.5 mm | |
| Length | 12.5 mm | |
| DC resistance | 120 mΩ | |
| Measuring frequency | 2.52 MHz | |
| Version | SMD choke | |
| Design | SMD | |
| Tolerance | ±20 % | |
| Inductance | 68 µH |
Download
Logistics
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
