SRR1260A-331K | Bourns Electronics GmbH
Power choke, SMD, 330 µH, SRR1260A-331K
Unit Price (€ / pc.)
1.8683 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
1.87 € *
Price list
Quantity
Price per unit*
1 pcs.
1.8683 €
10 pcs.
1.3447 €
100 pcs.
1.1424 €
2400 pcs.
0.7973 €
*incl. VAT plus shipping costs
Subject to prior sale
Power inductor, SRR1260A-331K, Bourns
Features
- Shielded construction
- Ferrite core
- AEC-Q200 compliant
- RoHS compliant
- Halogen free
Applications
- DC/DC converters
- Power supplies
- Automotive systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 330 µH | |
| Saturation current | 1.1 A | |
| Width | 12.5 mm | |
| Quality Q | Q 22 | |
| Length | 12.5 mm | |
| Design | SMD | |
| DC resistance | 580 mΩ | |
| Version | power choke | |
| Height | 6 mm | |
| Tolerance | ±10 % | |
| Measuring frequency | 0.796 MHz |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
