SRR1240-680M | Bourns Electronics GmbH
Power choke, SMD, 68 µH, SRR1240-680M
Order No.: 05D5623
EAN: 4099879998095
MPN:
SRR1240-680M
Unit Price (€ / pc.)
0.9401 € *
Standard delivery time from the manufacturer is: 20 Weeks
Power inductor, SRR1240-680M, Bourns
Features
- Height of 4.5 mm
- Ferrite core
- RoHS compliant
Applications
- Input/output of DC/DC converters
- Portable communications equipment
- Camcorders
- LCD TVs
- Car radios
Technical specifications
| Quality Q | Q 19 | |
| Saturation current | 1.5 A | |
| Width | 12.5 mm | |
| Height | 4 mm | |
| Length | 12.5 mm | |
| DC resistance | 200 mΩ | |
| Measuring frequency | 2.52 MHz | |
| Version | SMD choke | |
| Design | SMD | |
| Tolerance | ±20 % | |
| Inductance | 68 µH |
Download
Logistics
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
