SRP4012TA-1R0M | Bourns Electronics GmbH
Power choke, SMD, 1 µH, SRP4012TA-1R0M
Order No.: 05D5377
EAN: 4099879995803
MPN:
SRP4012TA-1R0M
Unit Price (€ / pc.)
0.7378 € *
Standard delivery time from the manufacturer is: 20 Weeks
Power inductor, SRP4012TA-1R0M, Bourns
Features
- Shielded construction
- Carbonyl powder core
- High saturation current
- Low profile
- RoHS compliant
Applications
- DC/DC converters
- Power supplies
- Automotive systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 1 µH | |
| Saturation current | 6 A | |
| Width | 4.06 mm | |
| Quality Q | Q 10 | |
| Length | 4.45 mm | |
| Design | SMD | |
| DC resistance | 47 mΩ | |
| Version | power choke | |
| Height | 1 mm | |
| Tolerance | ±20 % |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
