SRP1245A-100M | Bourns Electronics GmbH
Power choke, SMD, 10 µH, SRP1245A-100M
Order No.: 05D5643
EAN: 4099879998293
MPN:
SRP1245A-100M
Unit Price (€ / pc.)
1.2138 € *
Standard delivery time from the manufacturer is: 19 Weeks
Power inductor, SRP1245A-100M, Bourns
Features
- Shielded construction
- Carbonyl powder core
- High saturation current
- RoHS compliant
- Halogen free
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Quality Q | Q 20 | |
| Version | power choke | |
| Width | 12.5 mm | |
| Length | 13.5 mm | |
| Design | SMD | |
| Saturation current | 16 A | |
| Height | 4.8 mm | |
| Tolerance | ±20 % | |
| Inductance | 10 µH | |
| DC resistance | 25.5 mΩ |
Download
Logistics
| Property | Value |
|---|---|
| MSL | MSL 1 |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
