SRP1038A-470M | Bourns Electronics GmbH
Power choke, SMD, 47 µH, SRP1038A-470M
Unit Price (€ / pc.)
1.5589 € *
Next delivery: 500 pcs. on 2025-10-15
Total Price:
1.56 € *
Price list
Quantity
Price per unit*
1 pcs.
1.5589 €
10 pcs.
1.1067 €
100 pcs.
0.9520 €
500 pcs.
0.8211 €
1000 pcs.
0.7497 €
*incl. VAT plus shipping costs
Subject to prior sale
Power inductor, SRP1038A-470M, Bourns
Features
- Shielded construction
- Carbonyl powder core
- High saturation current
- RoHS compliant
- Halogen free
Applications
- DC/DC converters
- Automotive systems
- Power supplies
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Quality Q | Q 20 | |
| DC resistance | 167 mΩ | |
| Design | SMD | |
| Width | 10 mm | |
| Saturation current | 4.5 A | |
| Tolerance | ±20 % | |
| Version | power choke | |
| Height | 3.8 mm | |
| Length | 11 mm | |
| Inductance | 47 µH |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
