SRN8040TA-680M | Bourns Electronics GmbH
Power choke, SMD, 68 µH, 1650 mA, SRN8040TA-680M
Unit Price (€ / pc.)
0.3451 € *
Standard delivery time from the manufacturer is: 20 Weeks
Power inductor, SRN8040TA-680M, BOURNS
Features
- Semi-shielded construction
- Ferrite core
- Halogen free
- RoHS compliant
Applications
- DC/DC converters
- Power supplies
- Digital video cameras
- Televisions, LCD displays
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 68 µH | |
| DC current | 1650 mA | |
| Width | 8 mm | |
| Quality Q | Q 12 | |
| Length | 8 mm | |
| Design | SMD | |
| DC resistance | 205 mΩ | |
| Version | power choke | |
| Height | 6.3 mm | |
| Tolerance | ±20 % | |
| Measuring frequency | 1 MHz |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
| Original Packaging | Reel with 1,000 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
