SRN8040-470M | Bourns Electronics GmbH
Power choke, SMD, 47 µH, 1.4 A, SRN8040-470M
Order No.: 85D335
EAN: 4099889047936
MPN:
SRN8040-470M
Unit Price (€ / pc.)
0.4522 € *
Standard delivery time from the manufacturer is: 16 Weeks
Power inductor, SRN8040-470M, BOURNS
Features
- Semi-shielded construction
- High rated current
- Component height 4 mm
- Halogen free
- RoHS compliant
Applications
- DC/DC converters
- Notebook computers
- Digital video cameras
- Televisions, LCD displays
Technical specifications
| Version | power choke | |
| Inductance | 47 µH | |
| DC current | 1.4 A | |
| Tolerance | ±20 % | |
| DC resistance | 0.19 Ω | |
| Saturation current | 1.5 A | |
| Measuring frequency | 2.52 MHz | |
| Quality Q | Q 15 | |
| Design | SMD | |
| Length | 8.15 mm | |
| Width | 7.9 mm | |
| Height | 4 mm |
Download
Logistics
| Customs tariff number | 85045000 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
