SRN6028-470M | Bourns Electronics GmbH
Power choke, SMD, 47 µH, SRN6028-470M
Unit Price (€ / pc.)
0.2404 € *
Standard delivery time from the manufacturer is: On Request
Power inductor, SRN6028-470M, Bourns
Features
- Semi-shielded construction
- Ferrite core
- RoHS compliant
- Halogen free
Applications
- DC/DC converters
- Notebook computers
- Digital video cameras
- HDDs, cellphones
- Televisions, LCD displays
Technical specifications
| Quality Q | Q 11 | |
| Saturation current | 1 A | |
| Width | 6 mm | |
| Height | 2.8 mm | |
| Length | 6 mm | |
| DC resistance | 360 mΩ | |
| Version | power choke | |
| Design | SMD | |
| Tolerance | ±20 % | |
| Inductance | 47 µH |
Download
Logistics
| Country of origin | MY |
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
