SRN6028-3R3M | Bourns Electronics GmbH
Power choke, SMD 2424, 3.3 µH, 3.6 A, SRN6028-3R3M
Order No.: 75D6284
EAN: 4099889040937
MPN:
SRN6028-3R3M
Unit Price (€ / pc.)
0.2796 € *
Standard delivery time from the manufacturer is: On Request
Power inductor, SRN6028-3R3M, BOURNS
Features
- Semi-shielded construction
- Ferrite core
- Halogen free
- RoHS compliant
Applications
- DC/DC converters
- Notebook computers
- Digital video cameras
- Televisions, LCD displays
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | power choke | |
| Inductance | 3.3 µH | |
| DC current | 3.6 A | |
| Tolerance | ±20 % | |
| DC resistance | 34 mΩ | |
| Saturation current | 3.6 A | |
| Measuring frequency | 100 kHz | |
| Quality Q | Q 12 | |
| Design | SMD 2424 | |
| Length | 6 mm | |
| Width | 6 mm | |
| Height | 2.8 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Customs tariff number | 85045000 |
| Original Packaging | Reel with 1,000 pieces |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
