SRN5040-3R3M | Bourns Electronics GmbH
Power choke, SMD, 3.3 µH, SRN5040-3R3M
Order No.: 05D5687
EAN: 4099879998705
MPN:
SRN5040-3R3M
Unit Price (€ / pc.)
0.2713 € *
Standard delivery time from the manufacturer is: 16 Weeks
Power inductor, SRN5040-3R3M, Bourns
Features
- Semi-shielded construction
- Ferrite core
- RoHS compliant
- Halogen free
Applications
- DC/DC converters
- Notebook computers
- Digital video cameras
- HDDs, cellphones
- Televisions, LCD displays
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Saturation current | 3.8 A | |
| DC resistance | 27 mΩ | |
| Length | 5 mm | |
| Width | 5 mm | |
| Design | SMD | |
| Version | power choke | |
| Height | 4 mm | |
| Quality Q | Q 20 | |
| Inductance | 3.3 µH | |
| Tolerance | ±20 % |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
