DR331-513AE | Bourns Electronics GmbH
Choke, SMD, 51 µH, 500 mA, DR331-513AE
Unit Price (€ / pc.)
1.1781 € *
Available: 235 pcs.
Total Price:
11.78 € *
Price list
Quantity
Price per unit*
10 pcs.
1.1781 €
50 pcs.
1.0353 €
250 pcs.
0.8925 €
1500 pcs.
0.7259 €
3000 pcs.
0.6783 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD choke, DR331-513AE, BOURNS
Features
- Bifilar or sector windings
- Wide frequency range over 1000 MHz
- Ferrite core
- RoHS compliant
Applications
- Suppression of EMI in data
- Signal lines, e.g. CAN Bus
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height | 4.7 mm | |
| Inductance | 51 µH | |
| Version | SMD choke | |
| DC resistance | 300 mΩ | |
| Width | 5.4 mm | |
| Design | SMD | |
| Length | 9 mm | |
| DC current | 500 mA |
Download
Logistics
| Property | Value |
|---|---|
| MSL | MSL 1 |
| Customs tariff number | 85045000 |
| Country of origin | CN |
| Original Packaging | Reel with 1,500 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
