CM453232-102JL | Bourns Electronics GmbH
Choke, SMD, 1000 µH, 30 mA, CM453232-102JL
Order No.: 05D5842
EAN: 4099889000139
MPN:
CM453232-102JL
Unit Price (€ / pc.)
0.3332 € *
Next delivery: 500 pcs. on 2025-11-11
Total Price:
0.33 € *
Price list
Quantity
Price per unit*
1 pcs.
0.3332 €
10 pcs.
0.2332 €
100 pcs.
0.1999 €
500 pcs.
0.1737 €
1000 pcs.
0.1571 €
*incl. VAT plus shipping costs
Subject to prior sale
Chip inductor, CM453232-102JL, Bourns
Features
- High resistance to heat and humidity
- Resistance to mechanical shock and pressure
- Accurate dimensions for automatic surface mounting
- RoHS compliant
Applications
- Mobile phones
- Cellular phones
- CTV, VCR, HIC, FDD
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Quality Q | Q 30 | |
| DC resistance | 40 Ω | |
| DC current | 30 mA | |
| Design | SMD | |
| Width | 3.2 mm | |
| Tolerance | ±5 % | |
| Version | choke | |
| Measuring frequency | 0.252 MHz | |
| Height | 3.2 mm | |
| Length | 4.5 mm | |
| Inductance | 1000 µH |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
