CM322522-1R0KL | Bourns Electronics GmbH
Choke, SMD, 1 µH, 400 mA, CM322522-1R0KL
Unit Price (€ / pc.)
0.1309 € *
Standard delivery time from the manufacturer is: 18 Weeks
Chip inductor, CM322522-1R0KL, Bourns
Features
- High resistance to heat and humidity
- Resistance to mechanical shock and pressure
- Accurate dimensions for automatic surface mounting
- RoHS compliant
Applications
- Mobile phones
- Cellular phones
- CTV, VCR, HIC, FDD
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | choke | |
| DC resistance | 700 mΩ | |
| DC current | 400 mA | |
| Measuring frequency | 7.96 MHz | |
| Height | 2.2 mm | |
| Tolerance | ±10 % | |
| Width | 2.5 mm | |
| Length | 2.9 mm | |
| Design | SMD | |
| Inductance | 1 µH | |
| Quality Q | Q 30 |
Download
Logistics
| Property | Value |
|---|---|
| MSL | MSL 1 |
| Customs tariff number | 85045000 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
