CC453232A-100KL | Bourns Electronics GmbH
Choke, SMD, 10 µH, 700 mA, CC453232A-100KL
Order No.: 05D5939
EAN: 4099889000931
MPN:
CC453232A-100KL
Unit Price (€ / pc.)
0.3808 € *
Standard delivery time from the manufacturer is: 18 Weeks
Chip inductor, CC453232A-100KL, Bourns
Features
- High rated current
- High resistance to heat and humidity
- Resistance to mechanical shock and pressure
- Tight dimension tolerances for automatic placement
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 10 µH | |
| Length | 4.2 mm | |
| Design | SMD | |
| DC resistance | 480 mΩ | |
| Tolerance | ±10 % | |
| DC current | 700 mA | |
| Width | 3.2 mm | |
| Measuring frequency | 2.52 MHz | |
| Quality Q | Q 20 | |
| Height | 3.2 mm | |
| Version | choke |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
