PT61017PEL | Bourns Electronics GmbH
LAN transformer, 1:1, 350 µH, 0.6 Ω, PT61017PEL
Order No.: 05D5374
EAN: 4099889048537
MPN:
PT61017PEL
Unit Price (€ / pc.)
1.0948 € *
Standard delivery time from the manufacturer is: 24 Weeks
LAN transformer, PT61017PEL, Bourns
Features
- IEEE 802.3 Ethernet compatible
- Fully integrated for adapter, hub and motherboard applications
- RoHS compliant
Applications
- LAN
- Ethernet
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | LAN transformer | |
| Winding ratio | 1:1 | |
| Inductance | 350 µH | |
| Design | SMD | |
| min. frequency | 30 MHz | |
| max. frequency | 100 MHz | |
| DC resistance | 0.6 Ω | |
| Length | 12.8 mm | |
| Width | 6.9 mm | |
| Height | 5.65 mm | |
| min. operating temperature | 0 °C | |
| max. operating temperature | 70 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85177900 |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
