BK1697B | BK PRECISION
Laboratory power supply, 1 bis 40 VDC, outputs: 1 (5 A), 0 to 5 A, 200 W, 100-240 VAC, BK1697B
Order No.: 35K0016
EAN: 817050169713
MPN:
BK1697B
Unit Price (€ / pc.)
554.54 € *
Standard delivery time from the manufacturer is: 3 Weeks
DC Power supply, BK1697B, BK PRECISION
The BK1697B DC power supply is equipped with programming and protection features commonly found in more expensive performance instruments. Programming features include list mode for repetitive operation and 10 user-configurable voltage/current presets for quick recall. This benchtop power supply also supports adjustable voltage and current limits to protect the device under test.
Suitable for many applications including repetitive test routines in RandD, production testing, product evaluation, or in education environments.
Features
- Built-in voltage, current, and power meter
- Automatic CV/CC crossover operation
- Protection features: overvoltage (OVP), overcurrent (OCP), overtemperature (OTP) and key-lock function
- Store up to 10 voltage and current combinations for quick output
- Lightweight and compact
- Large back-lit LCD display
- Thermostatically-controlled fan with linear-speed control to minimize fan noise
Technical specifications
| Input voltage AC | 100-240 VAC | |
| efficiency | 70 % | |
| Output voltage DC | 1 to 40 VDC | |
| Depth | 215 mm | |
| Height | 98 mm | |
| Number of outputs | 1 | |
| Range of Output Currence | 0 to 5 A | |
| Output current | 5 A | |
| Width | 193 mm | |
| Power | 200 W |
Download
Logistics
| Customs tariff number | 85044095 |
| Country of origin | CN |
Compliance
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
