99 3782 202 08 | binder
Panel socket, M12, 8 pole, THT, screw locking, angled, 99 3782 202 08
Unit Price (€ / pc.)
53.8951 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
53.90 € *
Price list
Quantity
Price per unit*
1 pcs.
53.8951 €
5 pcs.
50.6702 €
15 pcs.
48.7186 €
50 pcs.
46.5647 €
150 pcs.
44.6131 €
*incl. VAT plus shipping costs
Subject to prior sale
Female panel mount connector, 99-3782-202-08, Franz Binder
M12-X Female connector, poles 8, shieldable, THT, IP67, UL
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 8 pole | |
| Type of locking | screw locking | |
| Contact connection | THT | |
| Product type | panel socket | |
| Coding | X | |
| Assembly | panel mounting | |
| Orientation | angled | |
| Degree of protection (IP) | IP67 | |
| Thread size | M12 | |
| contact surface | gold-plated |
Download
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
