99 0430 158 04 | binder
Jack, M12, 3 pole, screw connection, screw locking, straight, 99 0430 158 04
Unit Price (€ / pc.)
11.4002 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
11.40 € *
Price list
Quantity
Price per unit*
1 pcs.
11.4002 €
10 pcs.
10.5910 €
50 pcs.
9.8532 €
100 pcs.
8.8774 €
*incl. VAT plus shipping costs
Subject to prior sale
Female cable connector, 99 0430 158 04, binder
M12-A Female cable connector, Contacts: 3, 6.0-8.0 mm, unshielded, screw clamp, IP67, UL.
Technical specifications
| Pin number | 3 pole | |
| Type of locking | screw locking | |
| Additional parts | equipped | |
| Contact connection | screw connection | |
| Product type | jack | |
| Coding | A | |
| Assembly | cable assembly | |
| Orientation | straight | |
| Degree of protection (IP) | IP67 | |
| Thread size | M12 | |
| contact surface | CuSnZn |
Download
Logistics
| Customs tariff number | 85369010 |
| Country of origin | DE |
Compliance
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
