86 0132 0000 00012 | binder

Panel socket, M12, 12 pole, THT, screw locking, straight, 86 0132 0000 00012

Order No.: 70P2975
EAN: 4099891677749
MPN:
86 0132 0000 00012
Series: 763
86 0132 0000 00012 binder Sensor-Actuator Connectors Image 1
86 0132 0000 00012 binder Sensor-Actuator Connectors Image 2
Image may differ
Unit Price (€ / pc.)
22.3482 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
22.35 € *
Price list
Quantity
Price per unit*
1 pcs.
22.3482 €
10 pcs.
21.0035 €
50 pcs.
19.7540 €
100 pcs.
18.5640 €
*incl. VAT plus shipping costs
Subject to prior sale

Female panel mount connector, 86 0132 0000 00012, binder

M12-A Female panel mount connector, Contacts: 12, unshielded, THT, IP68, UL, PG 9.

Technical specifications
contact surface gold-plated
Thread size M12
Orientation straight
Degree of protection (IP) IP68
Type of locking screw locking
Product type panel socket
Pin number 12 pole
Assembly panel mounting
Additional parts equipped
Contact connection THT
Coding A
Logistics
Customs tariff number 85369010
Country of origin DE
Compliance
RoHS conform Yes
SVHC free No
Date of RoHS guidelines 3/31/15
