76 4331 0111 00012-0200 | binder

Panel plug, M12, 12 pole, strand connection, screw locking, straight, 76 4331 0111 00012-0200

Order No.: 70P2613
EAN: 4099891666064
MPN:
76 4331 0111 00012-0200
Series: 763
76 4331 0111 00012-0200 binder Sensor-Actuator Connectors Image 1
76 4331 0111 00012-0200 binder Sensor-Actuator Connectors Image 2
Image may differ
Unit Price (€ / pc.)
17.5525 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
17.55 € *
Price list
Quantity
Price per unit*
1 pcs.
17.5525 €
10 pcs.
16.3268 €
50 pcs.
15.1725 €
100 pcs.
14.1134 €
*incl. VAT plus shipping costs
Subject to prior sale

Sensor actuator cable, 76 4331 0111 00012-0200, binder

M12-A Male panel mount connector, Contacts: 12, unshielded, single wires, IP67, UL, M16x1.5.

Technical specifications
Filter Property Value
Thread size M12
Additional parts equipped
Pin number 12 pole
Orientation straight
Degree of protection (IP) IP67
Type of locking screw locking
Assembly panel mounting
Contact connection strand connection
contact surface gold-plated
Version cable 0.2 m
Product type panel plug
Logistics
Property Value
Country of origin DE
Customs tariff number 85369010
Compliance
Property Value
RoHS conform Yes
SVHC free No
Date of RoHS guidelines 3/31/15
