09 3421 81 04 | binder
Panel plug, M8, 4 pole, THT, snap-in/screw locking, straight, 09 3421 81 04
Unit Price (€ / pc.)
13.0662 € *
Standard delivery time from the manufacturer is: 11 Weeks
Total Price:
13.07 € *
Price list
Quantity
Price per unit*
1 pcs.
13.0662 €
10 pcs.
11.5192 €
50 pcs.
10.7338 €
150 pcs.
10.2578 €
500 pcs.
9.7461 €
*incl. VAT plus shipping costs
Subject to prior sale
Sensor-actuator connector, 09 3421 81 04, BINDER
M8 Male panel mount connector, Contacts: 4, shieldable, THT, IP67, front mounting.
Features
- Contact material: CuZn
- Pollution degree: 3
- Overvoltage category: I
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | panel plug | |
| Pin number | 4 pole | |
| Thread size | M8 | |
| Type of locking | snap-in/screw locking | |
| Orientation | straight | |
| Contact connection | THT | |
| contact surface | gold-plated | |
| Assembly | panel mounting | |
| Degree of protection (IP) | IP67 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85444290 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Substance description | Lead |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
