99 9106 403 03 | binder

Jack, 3 pole, solder connection, snap lock, straight, 99 9106 403 03

Order No.: 70P1270
EAN: 4099891701321
MPN:
99 9106 403 03
Series: 720
99 9106 403 03 binder Other Circular Connectors Image 1
99 9106 403 03 binder Other Circular Connectors Image 2
Image may differ
Unit Price (€ / pc.)
9.2701 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
9.27 € *
Price list
Quantity
Price per unit*
1 pcs.
9.2701 €
10 pcs.
8.3538 €
50 pcs.
7.6874 €
100 pcs.
6.7592 €
*incl. VAT plus shipping costs
Subject to prior sale

Female cable connector, 99 9106 403 03, binder

Snap-In IP67 (miniature) Female cable connector, Contacts: 3, 2.5-4.0 mm, unshielded, solder, IP67.

Technical specifications
Version jack
Cable cross-section 0.75 mm²
Pin number 3 pole
Orientation straight
Contact connection solder connection
Type of locking snap lock
Cable diameter 2.5 to 4 mm
Assembly cable assembly
Additional parts equipped
contact surface gold-plated
Shell Material PA
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free No
RoHS conform Yes
