Name: Jack, 24 pole, solder connection, screw locking, straight, 99 5496 15 24
Brand: binder
SKU: 70P0182
Price: 33.43 EUR
Availability: OutOfStock

Jack, 24 pole, solder connection, screw locking, straight, 99 5496 15 24

Order No.: 70P0182

EAN: 4099891694364

MPN:

99 5496 15 24

Series: 423

Image may differ

Key Specification:

Version jack

Cable cross-section 0.14 mm²

Pin number 24 pole

Orientation straight

Contact connection solder connection

Show 21 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

33.4271 € *

Available: 0 pcs.

Leadtime: 2 Weeks **

Add to Cart

Total Price:

33.43 € *

Price list

Quantity

Price per unit*

1 pcs.

33.4271 €

10 pcs.

31.4160 €

25 pcs.

29.2145 €

50 pcs.

27.1796 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Female cable connector, 99 5496 15 24, binder

M16 IP67 Female cable connector, Contacts: 24, 4.0-6.0 mm, shieldable, solder, IP67, UL.

Download

Technical Data Sheet - EN Technical Data Sheet

Manufacturer's catalogue - EN/DE Manufacturer's catalogue

Declaration of Conformity - EN Declaration of Conformity

Technical Data Sheet - DE Technical Data Sheet

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	DE
Customs tariff number	85369010

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	No

Accessory

Mounting key M16 for cable connector, 02 1785 000

Order No.:

66P0013

Manufacturer SKU:

02 1785 000

Available: 38 pcs. Leadtime: 6 Weeks **

1.05 € per pc. *

*incl. VAT plus shipping costs

**Subject to prior sale

Protective cap for jack, 08 1078 000 000

Order No.:

66F782

Manufacturer SKU:

08 1078 000 000

Available: 30 pcs. Leadtime: 6 Weeks **

4.38 € per pc. *

*incl. VAT plus shipping costs

**Subject to prior sale
