99 5109 760 04 | binder
Plug, 4 pole, crimp connection, screw locking, straight, 99 5109 760 04
Unit Price (€ / pc.)
16.0412 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
16.04 € *
Price list
Quantity
Price per unit*
1 pcs.
16.0412 €
10 pcs.
14.9226 €
50 pcs.
13.8873 €
100 pcs.
12.9115 €
*incl. VAT plus shipping costs
Subject to prior sale
Male cable connector, 99 5109 760 04, binder
M16 IP67 Male cable connector, Contacts: 4, 4.1-7.8 mm, shieldable, crimping, IP67.
Technical specifications
| Cable diameter | 4.1 to 7.8 mm | |
| Type of locking | screw locking | |
| Assembly | cable assembly | |
| Contact connection | crimp connection | |
| Cable cross-section | 0.14-1.0 mm² | |
| Pin number | 4 pole | |
| Version | plug | |
| Additional parts | unequipped | |
| Shell Material | CuZn | |
| Orientation | straight |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
