99 0582 106 07 | binder

Angle coupling, 7 pole, solder connection, screw locking, angled, 99 0582 106 07

Order No.: 70P1622
EAN: 4099891704353
MPN:
99 0582 106 07
Series: 723
99 0582 106 07 binder Other Circular Connectors Image 1
99 0582 106 07 binder Other Circular Connectors Image 2
Image may differ
Unit Price (€ / pc.)
28.6790 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
28.68 € *
Price list
Quantity
Price per unit*
1 pcs.
28.6790 €
10 pcs.
26.9535 €
25 pcs.
25.3232 €
50 pcs.
23.8119 €
*incl. VAT plus shipping costs
**Subject to prior sale

Female angled connector, 99 0582 106 07, binder

M16 IP67 Female angled connector, Contacts: 7 DIN, 4.0-6.0 mm, unshielded, solder, IP67.

Technical specifications
Version angle coupling
Cable cross-section 0.75 mm²
Pin number 7 pole
Orientation angled
Contact connection solder connection
Type of locking screw locking
Cable diameter 4 to 6 mm
Assembly cable assembly
Additional parts equipped
contact surface silver-plated
Shell Material PA
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free No
RoHS conform Yes
