09 4815 81 05 | binder
Panel plug, 5 pole, solder connection, push pull, straight, 09 4815 81 05
Unit Price (€ / pc.)
28.0483 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
28.05 € *
Price list
Quantity
Price per unit*
1 pcs.
28.0483 €
10 pcs.
26.3823 €
25 pcs.
24.7996 €
50 pcs.
23.3002 €
*incl. VAT plus shipping costs
Subject to prior sale
Miniature connector, 09-4815-81-05, BINDER
Push-Pull Male panel mount connector, Contacts: 5, shieldable, solder, IP67, front mounting.
Features
- Contact material: CuZn
- Pollution degree: 1
- Overvoltage category: I
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact connection | solder connection | |
| contact surface | gold-plated | |
| Orientation | straight | |
| Assembly | panel mounting | |
| Type of locking | push pull | |
| Pin number | 5 pole | |
| Version | panel plug |
Download
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
