09 0982 00 04 | binder

Panel socket, 4 pole, solder connection, bayonet locking, straight, 09 0982 00 04

Order No.: 66P1038
EAN: 4099889699456
MPN:
09 0982 00 04
Series: 710
09 0982 00 04 binder Other Circular Connectors Image 1
09 0982 00 04 binder Other Circular Connectors Image 2
Image may differ
Unit Price (€ / pc.)
9.3891 € *
Available: 4 pcs.
Total Price:
9.39 € *
Price list
Quantity
Price per unit*
1 pcs.
9.3891 €
10 pcs.
8.2705 €
100 pcs.
7.2471 €
250 pcs.
6.9734 €
1000 pcs.
6.5093 €
*incl. VAT plus shipping costs
Subject to prior sale

Subminiature connector, 09-0982-00-04, BINDER

Bayonet Female panel mount connector, Contacts: 4, unshielded, solder, IP40.

Features

  • Contact material: CuSn (Bronze)
  • Pollution degree: 1
  • Overvoltage category: I
Technical specifications
Type of locking bayonet locking
contact surface gold-plated
Assembly panel mounting
Contact connection solder connection
Pin number 4 pole
Version panel socket
Orientation straight
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
