09 0974 00 02 | binder
Panel socket, 2 pole, solder connection, bayonet locking, straight, 09 0974 00 02
Unit Price (€ / pc.)
5.8667 € *
Available: 17 pcs.
Total Price:
5.87 € *
Price list
Quantity
Price per unit*
1 pcs.
5.8667 €
10 pcs.
5.2717 €
50 pcs.
4.6410 €
100 pcs.
4.0341 €
*incl. VAT plus shipping costs
Subject to prior sale
Subminiature connector, 09-0974-00-02, BINDER
Bayonet Female panel mount connector, Contacts: 2, unshielded, solder, IP40.
Features
- Contact material: CuSn (Bronze)
- Pollution degree: 1
- Overvoltage category: I
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact connection | solder connection | |
| contact surface | gold-plated | |
| Orientation | straight | |
| Assembly | panel mounting | |
| Type of locking | bayonet locking | |
| Pin number | 2 pole | |
| Version | panel socket |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
