09 0416 80 05 | binder

Panel socket, 5 pole, solder connection, screw locking, straight, 09 0416 80 05

Order No.: 66P0745
EAN: 4099889699265
MPN:
09 0416 80 05
Series: 712
09 0416 80 05 binder Other Circular Connectors Image 1
09 0416 80 05 binder Other Circular Connectors Image 2
Image may differ
Unit Price (€ / pc.)
14.2086 € *
Available: 224 pcs.
Leadtime: On Request **
Total Price:
14.21 € *
Price list
Quantity
Price per unit*
1 pcs.
14.2086 €
10 pcs.
12.5069 €
50 pcs.
11.6501 €
150 pcs.
11.1503 €
500 pcs.
10.5553 €
*incl. VAT plus shipping costs
**Subject to prior sale

Subminiature connector, 09-0416-80-05, BINDER

M9 IP67 Female panel mount connector, Contacts: 5, unshielded, solder, IP67, front mounting.

Features

  • Contact material: CuSn (Bronze)
  • Pollution degree: 1
  • Overvoltage category: I
Technical specifications
Type of locking screw locking
contact surface gold-plated
Assembly panel mounting
Contact connection solder connection
Cable cross-section 0.25 mm²
Pin number 5 pole
Version panel socket
Additional parts equipped
Orientation straight
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
