09 0066 70 07 | binder

Panel socket, 7 pole, solder connection, bayonet locking, straight, 09 0066 70 07

Order No.: 70P0827
EAN: 4099891700034
MPN:
09 0066 70 07
Series: 690
09 0066 70 07 binder Other Circular Connectors Image 1
09 0066 70 07 binder Other Circular Connectors Image 2
09 0066 70 07 binder Other Circular Connectors Image 3
Image may differ
Unit Price (€ / pc.)
28.2506 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
28.25 € *
Price list
Quantity
Price per unit*
1 pcs.
28.2506 €
10 pcs.
26.5370 €
25 pcs.
24.9662 €
50 pcs.
23.4668 €
*incl. VAT plus shipping costs
**Subject to prior sale

Female panel mount connector, 09 0066 70 07, binder

Bayonet Female panel mount connector, Contacts: 7, shieldable, solder, IP40.

Technical specifications
Type of locking bayonet locking
contact surface silver-plated
Assembly panel mounting
Contact connection solder connection
Cable cross-section 0.75 mm²
Pin number 7 pole
Version panel socket
Additional parts equipped
Shell Material PBT
Orientation straight
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
