UPSI-2406R2IP-38AC | Bicker Elektronik
UPS in IP housingUPSI-2406R2IP-38AC
NCNR (non cancelable / non returnable)
Uninterruptible power supply, UPSI-2406R2IP-38AC, Bicker Elektronik
The AC/DC UPS UPSI-2406R2IP-38AC guarantees an uninterruptible 24V DC power supply for control modules, embedded box IPCs, drives, actuators, sensors, safety technology and many more in harsh industrial and mobile applications. With the AC/DC UPS UPSI-2406R2IP-38AC, you protect your 24V application in the event of a power failure, voltage dip or flicker! The intelligent DC emergency power supply with AC wide-range input thus reliably avoids system failures, system downtime & data loss. The IP65-protected AC/DC UPS is the ideal choice for particularly extreme environments. Typical applications include heavy industry, petrochemicals, tunnelling and mining, security and building services, energy, communications, lighting, commercial and special vehicles, food industry, chemicals and agriculture.
Features
- Outdoor AC/DC UPS for extreme environments
- Robust aluminium housing with IP65 protection
- Effective charging at sub-zero temperatures
- Intelligent input current regulation
- Regulated output voltage in backup mode
- Pressure compensation element to prevent condensation inside
- Input and output cable firmly installed
- On/Off function via push button
| Filter | Property | Value |
|---|---|---|
| Output current | 6 A | |
| Output voltage DC | 24 VDC | |
| Input voltage AC | 100-240 VAC | |
| Power | 144 W | |
| Length | 370 mm | |
| Width | 130 mm | |
| Height | 130 mm | |
| min. operating temperature | -20 °C | |
| max. operating temperature | 50 °C |
| Property | Value |
|---|---|
| Customs tariff number | 85044083 |
| Country of origin | DE |
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
