ACDC-54NAV | BEHA-AMPROBE
TRMS AC/DC current clamp ACDC-54NAV, 1000 A (DC), 1000 A (AC), 1000 V (DC), 1000 V (AC), CAT III 1000 V, CAT IV 600 V
Order No.: 27K0785
EAN: 4099891457686
MPN:
ACDC-54NAV
3729989
Unit Price (€ / pc.)
634.8174 € *
Standard delivery time from the manufacturer is: 2 Weeks
Power meter clamp, 3729989, BEHA-AMPROBE
Providing the full range of diagnostic functions, including phase sequence, power and power factor, total harmonic distortion and individual harmonics, inrush current, and low-pass filter, the Amprobe Navigator clamp multimeter is the first choice for sampling and checking system conditions before using heavy-duty specialized tools - and before additional costs are incurred. It is a measuring instrument with measuring circuit category CAT IV 600 V, CAT III 1,000 V with voltage measurement up to 1,000 V AC/DC. The innovative function joystick of the clamps replaces various function keys and facilitates the operation enormously. This innovative navigation allows the user to quickly switch between different functions.
Features
- True RMS measurement AC+DC (TRMS)
- Automatic flashlight function when opening the clamp
- Non-contact voltage detection
- Functions selectable via joystick
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. voltage measuring range (AC) | 1000 V | |
| max. resistance range | 100 kΩ | |
| max. voltage measuring range (DC) | 1000 V | |
| Surge voltage category | CAT III 1000 V, CAT IV 600 V | |
| max. measured value (frequency) | 10 kHz | |
| max. measured current value (AC) | 1000 A | |
| Product type | AC/DC current clamp | |
| max. measured current value (DC) | 1000 A | |
| min. Measured value (frequency) | 20 Hz | |
| TRMS possible | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 90303100 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
